ws2812b… again… Sorry… on F4

You are not allowed to mix the cores.
Either use Roger’s one, or stick to generic as detected from your log:
Arduino\hardware\STM32GENERIC\STM32\libraries\SPI\src/SPI.h

Oh….

In that case what else would I need to do to get the library to run?

And to add, just tested, It also doesnt compile on rogers F4 core. Only the f1 cores.

If you would post the error codes we might be able to help.

Alternatively, you could give it a try with my repo, is further developed than Roger’s core regarding F4 stuff.

I commented out wireing private, as it was included but was an empty file….

installed your core

https://pastebin.com/dLARf02H

my guess is something to do with the way it calls dma transfer. i honestly dont know… My brain is turning into mush

I see, there is a missing DMA related function in the SPI lib for F4.
It needs to be implemented, which takes time, a missing ingredient.

Im assuming just copying the f1 SPI library wont work?

It won’t work, the DMA of F4 is different from F1.

[stevestrong – Sun Mar 25, 2018 9:06 am] –
You are not allowed to mix the cores.
…

Words of pure wisdom. … in addition to not mixing the cores, one also should not cross-the-streams.

Egon: Don’t cross the streams.
Peter: Why?
Egon: It would be bad.
Peter: I’m fuzzy on the whole good/bad thing. What do you mean “bad”?
Egon: Try to imagine all life as you know it stopping instantaneously and every molecule in your body exploding at the speed of light.
Raymond: Total protonic reversal.
Peter: That’s bad. Okay. Alright, important safety tip, thanks Egon.


That would be bad :p

So do you feel this library would work, if the SPI library was updated to include all the functions?

[Nutsy – Mon Mar 26, 2018 6:31 pm] –
So do you feel this library would work, if the SPI library was updated to include all the functions?

Is that not what Steve implied here?

[stevestrong – Sun Mar 25, 2018 1:24 pm] –
I see, there is a missing DMA related function in the SPI lib for F4.
It needs to be implemented, which takes time, a missing ingredient.

Frédéric (and team) have done a good job with the Nucleo F4 boards
STM32F4

• Nucleo F401RE
• Nucleo F411RE
• Nucleo F429ZI
• Nucleo F446RE
• STM32F407G-DISC1

and the wrappers for CubeMX + HAL.

The F4 support in libmaple has been somewhat weak from the start; Steve has made remarkable inroads with advancing the code, but I understand priorities and time constraints – which is why I simply shy away from backend core work … difficult to please the crowds.

IMO, the longterm solution to STM32 & ArduinoIDE is the https://github.com/stm32duino/Arduino_Core_STM32 … it is Official, it is supported, it utilizes current STM thinking on tools, and migrating to pro-tools is straightforward.

Ray

[Nutsy – Mon Mar 26, 2018 6:31 pm] –
So do you feel this library would work, if the SPI library was updated to include all the functions?

Yes, it is the function dmaSendAsync(), which was implemented by Victor for F1.
It is not yet ported to F4.

I have ported the dmaSendAsync() function to my F4 repo, you may give it a try.

I havnt got my main dev computer running…

But i just tried to compile the strand test, copying the library over from the f1 lib directory… and commenting out the wire private include.

Sadly still didnt compile…

https://pastebin.com/Ey5Hf2rs << the error

You should get my repo, it was updated 2 days ago with the changes related to “__IO”

I really thought I did… :/

Will try again now.

Yeah still getting the error
https://pastebin.com/qN9aZ8cL

I have corrected the errors occurred during conflict merging the __IO stuff.
It should compile now error free.

Excellent… I cant do an in depth test with regards to the neo pixels… but it does indeed compile. When i get my main rig back up and running (waiting for PSU) i can do a propper test

Thanks Steve, this is a great help
